Product Details:
|
Model NO.: | PE600*900 | Inlet Size: | 900*600mm |
---|---|---|---|
Condition: | New | Warranty: | 1 Year |
After-sales Service: | 1 Year | Product Name: | PE Jaw Crusher |
After-Sale Service: | Problems Within 48 Hours | Quality: | Advanced Technology |
The Machines Classification: | Jaw Crusher Machine | Color: | Any |
Installation: | Under Technical Guidance | Capacity: | 90-180tph |
Transport Package: | Industrial Standard | Specification: | ISO, CE |
Trademark: | Dingbo Machinery | Origin: | Shanghai, China |
HS Code: | 8474209000 | Supply Ability: | 90-180tph |
Type: | Jaw Crusher | Motor Type: | AC Motor |
Motor Power: | 55-75kw | Application: | Construction |
Materials: | Limestone | Outlet Size: | 65-140mm |
Customization: | Available | Customized Request |
1.High crushing ratio,uniform particle size
Model | Feed Size | Feeding Opening Size (mm) | Max.Feeding Size(mm) | Adjustment Range of Discharging Opening (mm) | Capacity(t/h) | Power(kw) | Overall Drmension (mm) |
PE-250×400 | 400×250 | 210 | 20-80 | 5-20 | 15 | 1430×1315×1296 | |
PE-400×600 | 600×400 | 350 | 40-100 | 15-65 | 30 | 1700×1732×1653 | |
PE-500×750 | 500×750 | 425 | 50-100 | 45-110 | 55 | 2035×1921×2000 | |
PE-600×900 | 900×600 | 480 | 65-140 | 90-180 | 55-75 | 2290×2206×2370 | |
PE-750×1060 | 1060×750 | 630 | 80-160 | 110-320 | 110 | 2655×2302×3110 | |
PE-900×1200 | 900×1200 | 750 | 100-200 | 200-400 | 132 | 3380×2870×3330 | |
PE-1000×1200 | 1000×1200 | 850 | 195-260 | 220-450 | 160 | 3480×3876×3330 | |
PE-1200×1500 | 1200×1500 | 1020 | 150-300 | 400-800 | 180-220 | 4200×3750×3820 | |
PEX-150×250 | 150×250 | 125 | 10-40 | 1-5 | 5.5 | 875×758×850 | |
PEX-150×750 | 150×750 | 125 | 18-48 | 5-16 | 15 | 1200×1500×1200 | |
PEX-250×400 | 400×250 | 210 | 25-80 | 15-30 | 22-30 | 1667×1545×1020 | |
PEX-250×1000 | 1000×250 | 210 | 25-60 | 16-50 | 30-37 | 1530×1992×1380 | |
PEX-250×1200 | 1200×250 | 210 | 25-60 | 20-60 | 37 | 1900×2192×1430 | |
PEX-300×1300 | 1300×300 | 250 | 25-105 | 20-90 | 75 | 2720×1950×1600 |
