Vibration Polishing Machine for Powder Pulverizing Marble Grinding Limestone Milling

Large Image : Vibration Polishing Machine for Powder Pulverizing Marble Grinding Limestone Milling

Product Details:

Place of Origin:	China
Certification:	ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, QC 080000

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	Normal Packing Ls in Wooden Cases
Delivery Time:	Peak Season Lead Time: 1-3 months, Off Season Lead Time: one month
Payment Terms:	LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Supply Ability:	100sets/Month

Contact Now

Vibration Polishing Machine for Powder Pulverizing Marble Grinding Limestone Milling

Description

Model NO.:	MTM 100/MTM130/MTM160/MTM175	Application:	Ceramics, Jadestone, Cement Brick, Concrete Curb, Granite, Marble
Type For Grinding Machine:	Special Grinding Machine	Grinding Machine Type:	Vibration Polishing Machine
Grinding Method:	Dry Grind	Condition:	New
After-Sale Service:	For Whole Using Life	Spare Parts Supply:	For Whole Year
Test&Installation:	Professional Engineer Assigned	Mining Object:	Cement Grinding Machine
Transport Package:	Standard Packaging	Specification:	National Standard
Trademark:	Dingbo Machinery	Origin:	China
HS Code:	84742090	Supply Ability:	20 Sets Per Month
After-sales Service:	1year	Warranty:	1year
Type:	Stone Grinding Machine	Control:	Artificial
Automation:	Semi-automatic	Precision:	Normal Precision
Customization:	Available \| Customized Request

powder pulverizer,marble grinding machine,limestone milling machine
Description Of MTM Series Grinding Mill
MTM High Pressure Mill is built on advanced technology with a combination of domestic applications.And the MTM series griding mill is widely used in grinding materials processing of mineral products in industries such as metallurgy, building materials, chemicals, mining minerals , can be grinding quartz, feldspar, calcite, talc, barite, fluorite, rare earths, marble, ceramic. It suitable for processing various non-explosive mineral materials with theMohs hardness not higher than 9.3 and the humidity below 6% . The franularity of the finished powder size can be adjusted between 30mesh and 325 mesh.For the easy operation and low cost with high efficiency, our griding mill has become one of the most popular milling machine in the world.
Characteritcs of Micro Powder Grinding Mill:
1. For fine and superfine powder making.Micro powder grinding mill is applicable for making fine and superfine powder between 47 and 5micron (325-2500 mesh), comparable for coarse powder made by raymond mill.
2. EconomicalMicro powder grinding mill capacity can reach to 0.6-6.5T/H, it is an economical equipment compare with ball mill, turbo mill and jet mill. It is very suitable for industiral use.
3. Enviornment friendlyDMC120 bag filter not only can reduce the noise of machine, but also can catch fine powder to reduce pollution.
Work Principle of Dingbo MTM Series Grinding Mill
The working principle is as follows: Load the stuff for grinding evenly and continuously into the grinding chamber of the main frame. Due to the centrifugal force in rotation, the roller swings go outward and presses closely upon the ring. The shovel carries the stuff to the space between the roller and ring. When the roller rolls, the stuff is thus grinded.After being grinded, the stuff is to be routed to the classifier along wind belt of the blower and the rough powder will be put back to the grinder for regrinding.powder pulverizer,marble grinding machine,limestone milling machine wear partOur Services-Pre-sale servicesBased on the clients' request and budget, we will offer equipment pictures, working site videos, plant processing diagram, assemble drawings, foundation drawings, and plant layout. Clients are welcome to visit our factory, also our equipment working site from former clients. We will arrange cars, hotels and translators for the visiting customers.-Sale servicesOur experienced technicians is available on the phone also the internet, clients can get instance guidance by telephone, email, online service anytime, anywhere. As clients' request, we will send technician to the mine site to guide the installation, trial run test, and training operators until the plant works normally.-After-sale servicesNormally, the equipment warranty is 18 months since installation, but can extend as long as 24 months as the clients' request. Equipment spares will be offered with manufacturing cost in at least 10 years since the order is placed. To establish long term cooperation, we will regularly call and email our clients, to check the equipment working condition, offer suggestions for maintenance, and if necessary we will pay a visit to clients to solve the problems caused during equipment working.
1. Quality control
All the equipment offered by shanghai dingbo are produced by China national standard drawings, nonstandard equipment will be produced by the drawings confirmed by clients. shanghai dingbo Machinery strictly follows ISO 9001: 2008 and CE Quality management system. Most equipment will be test for at least 8 hours in the factory before delivery. There is record in computer for each equipment, spares can be easily confirmed when it is necessary.
2. Way of paymentWelcome clients place the order by online one-touch! shanghai dingbo also offers various ways of payment, T/T, against copy of B/L, L/C, D/A, D/P, West union, etc. All can be negotiated.
3. Delivery timeNormal delivery time within 10 to 20 working days, complete production line or larger equipment may take longer. Exact delivery shall be confirmed when place the order.
4. Trade termsTypically EXW, FOB, CIF, CFR, DAF follows International Rules for the Interpretation of Trade Terms 2010(INCOTERMS 2010).
5. Shipping lines
Priority rule based on clients' request, and freight cost, service, shipping date, date of arrival shall be considered.
6. Installation
shanghai dingbo has several experienced technicians with passports ready to go for installation, when installation service is needed, the client should pay for technicians' round way air tickets, salary(shall be confirmed before leaving), food and lodging, most importantly to guarantee the technicians' safety.
7. Equipment warranty
Equipment from dingbo with 15months warranty, can be extended to 20months as request.About us Company ImformationShanghai Ding Bo heavy industry machinery co., LTD is the pioneer enterprise of mining technology and equipment, at the core of the Yangtze river delta economic zone ofsea, convenient - Shanghai, is effectively combine advanced technology with the traditional technology of high-tech enterprises.Main ProductsShanghai Ding Bo heavy industry machinery co., LTD. Has the abundant technical force and strong production capacity, the company's products in mining, roads, Bridges, housing construction and other industries widely used, crusher, grinding machine, feeding machine, vibrating screen, sand washer, belt conveyor equipment and series of products, all passed the ISO9001:2008 standard quality certification
FAQ
In order to recommend the suitable models and supply more complete quotation for you, Send yourRequiry Details in the below!Include:
1. Which machine do you need?
(such as crusher, grinder, vibrating screen, vibrating feeder, belt conveyor and other benefication equipment)
2. Which kind of material you are going to process?
Soft stone (dolomite, limestone and others) or hard stone (granite, basalt, river pebble and others) ?
3. What's the production capacity you want?
How many tons or cubic meters per hour?
4. You want only a machine or a complete production line?
And please tell me your email and phone, I will give you factory price with full specification and you will know all details about machine and discount.
CE and ISO9001:2008 Certificate

High pressure Suspension Grinding Mill
Spec.	Rollern umber	Roller Size(MM)	MaxFeed size(MM)	Finishe dsize(MM)	Overall size LxWxH(mm)	Electric power(KW)	Electric power(KW)fan	WhenThe yield(T)
YGM7815	3	*260150**	15-20	0.613-0.033	*430035005100*	18.5	15	0.8-2
YGM8314	3	*270140**	15-20	0.613-0.033	*530041005200*	22	22	1-3
YGM9517	4	*310170**	15-25	0.613-0.033	*710059007900*	37	37	2.1-5.6
YGM4121	5	*410210**	15-25	0.613-0.033	*785080009700*	75	75	2.8-10.5
MTM160	6	*440270**	20-35	0.613-0.033	*1255057008350*	132	132	5-20
MTM175	5	*520280**	25-40	0.6-0.045	*1257595559916*	160	200	13-25
