High Capacity Construction Impact Crusher with 60-520tph Efficiency

Certification
China Shanghai Dingbo Heavy Industry Machinery Co., Ltd certification
China Shanghai Dingbo Heavy Industry Machinery Co., Ltd certification
I'm Online Chat Now

High Capacity Construction Impact Crusher with 60-520tph Efficiency

High Capacity Construction Impact Crusher with 60-520tph Efficiency
High Capacity Construction Impact Crusher with 60-520tph Efficiency High Capacity Construction Impact Crusher with 60-520tph Efficiency High Capacity Construction Impact Crusher with 60-520tph Efficiency High Capacity Construction Impact Crusher with 60-520tph Efficiency High Capacity Construction Impact Crusher with 60-520tph Efficiency High Capacity Construction Impact Crusher with 60-520tph Efficiency

Large Image :  High Capacity Construction Impact Crusher with 60-520tph Efficiency

Product Details:
Place of Origin: China
Brand Name: dBm( Sand Making Machine )
Certification: ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, QC 080000
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Normal Packing Ls in Wooden Cases
Delivery Time: Peak Season Lead Time: 1-3 months, Off Season Lead Time: one month
Payment Terms: LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Supply Ability: 100sets/Years

High Capacity Construction Impact Crusher with 60-520tph Efficiency

Description
Model NO.: VSI-7611 Condition: New
Color: Black Name: Sand Making Machine
After-Sale Service: Problems Within 48 Hours Quality: Advanced Technology
Capacity: 60-520tph Transport Package: Standard Packaging
Specification: National Standard Trademark: Dingbo Machinery
Origin: China HS Code: 84742090
Supply Ability: 20 Sets Per Month After-sales Service: 1year
Warranty: One Year Type: Impact Crusher
Application: Machinery & Hardware, Construction, Mineral Industry, Stone Industry Drive: Piezoelectric
Crushing Style: Impact Customization: Available | Customized Request

Product Description

Impact High-Efficient Sand Maker CrusherImpact High-Efficient Sand Maker CrusherImpact High-Efficient Sand Maker CrusherImpact High-Efficient Sand Maker CrusherImpact High-Efficient Sand Maker CrusherImpact High-Efficient Sand Maker CrusherImpact High-Efficient Sand Maker CrusherThe sand making machine integrates three crushing modes, and can continuously work for 720 hours. Higher crushing chamber, greater crushing impact. During the parts and material procurement, production and processing, the quality is strictly controlled. Wearing parts is optimally allocated for longer service life.

Hydraulic autonomous system: Convenient maintenance, high performance, low failure rate. The whole frame adopts elastic reinforcement technology, eliminating the problems like easy fracture of motor frame.

Working principle:
The materials go into the crusher from the feed hopper and are separated into two parts by the distributor. One part goes into the impeller rotating with high speed from the middle of the distributor, and is quickened inside the impeller, and the acceleration can reach hundred times of the acceleration of gravity, and then the materials will cast from the three uniformly distributed runners of the impeller at a speed of 60-70m/s, and impact and crush with the other part of materials which fall from around the distributor and then they will together impact to the material lining inside the vortex cavity. Bounced from the material lining, the materials will impact obliquely upward to the top of the whirling motion chamber which will change their movement direction again, so that materials will move down, and the materials launching from the runners of the impeller will form a continuous material curtain. In this way, the materials will get two times or more hitting, friction, grinding and crushing effect inside the whirling motion crushing chamber. The crushed materials will be discharged from the bottom discharging mouth. This process will form a closed-circuit system together with the cyclic screening system and generally speaking, after three times of cycle, the materials will be crushed below 20Moh.
Our Advantages

Advantages and Features:
1. Simple structure, easy to set up and repair, low cost in operation;
2. High production of crushing, has the function of fine crushing and rough grinding;
3. Excellent shape of product, mainly the product shape is cubic with small fraction of elongated flaky particle shape, suitable for aggregate shaping, manufactured sand.
4. It is little affected by the moisture content of materials, and the content can get up to about 8%.
5. It is suitable to crush medium hard and ultra-hard materials.
6. Working noise is lower than 75 decibel, less dust pollution.
model VSI7611 VSI8518 VSI9526 VSI1140
Capacity(t/h) Feeding  at  center  and  sizes 120-180 200-260 300-380 450-520
All  feeding  at  center 60-90 100-130 150-190 225-260
Max. feeding  size(mm) Soft  material < 35 < 40 < 45 < 50
Hard  material < 30 < 35 < 40 < 45
Rotating  speed(r/min) 1700-1890 1520-1690 1360-1510 1180-1310
Double  electric  motor  power(kw) 110 180 264 400
Overall  dimension(mm) 3700*2150  *2100 4140*2280  *2425 4560*2447  *2778 5000*2700  *3300
Weight  (t) 7.8 10.3 16 22
voltage 380v; 50Hz
